Rapier®
Industrial Type 3 fire hose with potable water capability
The trusted Rapier fire hose has been enhanced for even greater versatility. It features a robust TPU internal lining that’s seamlessly bonded to its textile reinforcement – ensuring lasting strength and reliability in demanding conditions.
Its tough PVC/Nitrile rubber blend outer cover resists abrasion and wipes clean easily from oils, dirt, and grime. AS 2792 Type 3-certified fire hose in popular sizes, Rapier remains a go-to choice for fire brigades and industrial applications.
New! Rapier is now available with a blue lining that meets AS/NZS 4020 standards for safe drinking water use, making it ideal for temporary water bypass systems in municipal and mining environments.
This lightweight low-volume hose is available in red, with yellow, blue, and green options to help distinguish between fire hose (red) and wash-down hose (blue) on the same industrial site. Rapier requires no drying, stores compactly, and is compatible with a wide range of securely fitted couplings.
Crusader Hose offers a wide range of couplings securely fitted to the hose. A test certificate can be provided if required. This allows you to confidently protect life and property with a fully approved and tested fire hose.
Technical Data
| Diameter (ID) | 25 mm | 38 mm | 45 mm | 51 mm | 64 mm | 79 mm |
| 1" | 1.5" | 1.75" | 2" | 2.5" | 3" | |
| Max. working pressure* | 2100 kPa | 2100 kPa | 2100 kPa | 2100 kPa | 2100 kPa | 1400 kPa |
| Min. burst pressure | 5250 kPa | 5250 kPa | 5250 kPa | 5250 kPa | 5250 kPa | 3500 kPa |
| Weight/m | 0.19 kg | 0.30 kg | 0.36 kg | 0.43 kg | 0.56 kg | 0.82 kg |
| 30 m coil diameter | 0.46 m | 0.48 m | 0.48 m | 0.48 m | 0.51 m | 0.52 m |
| AS 2792 approved | ✓ | ✓ | - | ✓ | ✓ | - |
| AN/NZS 4020 approved | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ |
| Part # ** | HHR025XRA | HHR038XRA | HHR045XRA | HHR051XRA | HHR064XRA | HHR079XRA |
*Dependent on maximum working pressure of attached couplings if lower.
**Replace 8th character of part # for different colours: R = Red U = Blue Y = Yellow N = Nato Green
Large choice of diameters & lengths
Available sizes in standard 30 m lengths and longer lengths up to 200 m: 25 mm, 38 mm, 45 mm, 51 mm, 64 mm, and 79 mm.
Long-lasting & high-quality product
Features
- Abrasion-resistant
- High working pressure 2100 kPa
- Potable water approved AS/NZS 4020
- Easy to clean
- Lightweight & quick to deploy
- Synthetic – no drying
- Assembly & fittings available
- Available in a variety of colours
- Australian Made
Primary uses
- Firefighting
- Wash-down
- Dewatering
- Water transfer
