Rapier®

Colour-code your fire hose

Rapier®

Industrial Type 3 fire hose with potable water capability

The trusted Rapier fire hose has been enhanced for even greater versatility. It features a robust TPU internal lining that’s seamlessly bonded to its textile reinforcement – ensuring lasting strength and reliability in demanding conditions.

Its tough PVC/Nitrile rubber blend outer cover resists abrasion and wipes clean easily from oils, dirt, and grime. AS 2792 Type 3-certified fire hose in popular sizes, Rapier remains a go-to choice for fire brigades and industrial applications.

New! Rapier is now available with a blue lining that meets AS/NZS 4020 standards for safe drinking water use, making it ideal for temporary water bypass systems in municipal and mining environments.

This lightweight low-volume hose is available in red, with yellow, blue, and green options to help distinguish between fire hose (red) and wash-down hose (blue) on the same industrial site. Rapier requires no drying, stores compactly, and is compatible with a wide range of securely fitted couplings.

Crusader Hose offers a wide range of couplings securely fitted to the hose. A test certificate can be provided if required. This allows you to confidently protect life and property with a fully approved and tested fire hose.

Technical Data

Diameter (ID)25 mm38 mm45 mm51 mm64 mm79 mm
1"1.5"1.75"2"2.5"3"
Max. working pressure*2100 kPa2100 kPa2100 kPa2100 kPa2100 kPa1400 kPa
Min. burst pressure5250 kPa5250 kPa5250 kPa5250 kPa5250 kPa3500 kPa
Weight/m0.19 kg0.30 kg0.36 kg0.43 kg0.56 kg0.82 kg
30 m coil diameter0.46 m0.48 m0.48 m0.48 m0.51 m0.52 m
AS 2792 approved--
AN/NZS 4020 approved
Part # **HHR025XRAHHR038XRAHHR045XRAHHR051XRAHHR064XRAHHR079XRA

*Dependent on maximum working pressure of attached couplings if lower.

**Replace 8th character of part # for different colours: R = Red U = Blue Y = Yellow N = Nato Green

Large choice of diameters & lengths

Available sizes in standard 30 m lengths and longer lengths up to 200 m: 25 mm, 38 mm, 45 mm, 51 mm, 64 mm, and 79 mm.

Long-lasting & high-quality product

Rapier is manufactured at our Australian factory under stringent quality standards. Each length is individually tested and comes with a 12-month warranty.

Features

Primary uses
