Waterlord® HP
Unyielding under pressure
Waterlord® HP
Extra high-pressure layflat hose
Waterlord® HP is a durable, high-pressure hose rated up to 5000 kPa, designed for efficient water transfer across mine sites and other industrial environments. It features a high-tensile polyester textile reinforcement and an abrasion-resistant polyurethane cover, offering reliable protection against rough terrain. Optional reel systems simplify handling of large diameters, and Waterlord connects easily to existing infrastructure using flanges or couplings—making it an ideal solution for inland pipeline and mining applications.
Technical Data
| Diameter (ID) | 76 mm HP | 102 mm HP | 152 mm HP | 203 mm HP |
| 3" | 4" | 6" | 8" | |
| Max. working pressure* | 5000 kPa | 5000 kPa | 4000 kPa | 3000 kPa |
| Min. burst pressure | 10000 kPa | 10000 kPa | 8000 kPa | 6000 kPa |
| Bend radius @ 60 psi | 1.6 m | 2.1 m | 3.2 m | 4 m |
| Tensile load | 10 t | 15 t | 25 t | 35 t |
| Weight/m | 1.4 kg | 2.2 kg | 3.5 kg | 5 kg |
| Avg. single wall thickness | 4.5 mm | 5 mm | 6.5 mm | 6.5 mm |
| Part # | HWH076XBA | HWH102XBA | HWH152XBA | HWH203XBA |
*Dependent on maximum working pressure of attached couplings if lower.
Large choice of diameters & lengths
Available sizes in lengths up to 200 m: 76 mm, 102 mm, 152 mm and 203 mm
Long-lasting & high-quality product
All hose is fully manufactured at our Australian factory under stringent quality standards. Each length is individually tested and comes with a 12-month warranty.
Features
- Handles high-pressure pumping with ease
- Lightweight and portable for easy transport
- Reel systems available for managing long lengths and large diameters
- Quick-connect couplings for fast and secure setup
- Abrasion-resistant material suitable for mixed and rugged terrain
- Proudly Australian Made
Ideal For
- Mine dewatering operations
- Industrial high-pressure water transfer
- Projects requiring rapid hose deployment
- Applications with limited storage space
- Situations demanding easy transport and handling
Download Product Information
Frequently Asked Questions
FAQs
Waterlord hoses replace rigid poly with a flexible, continuous-length system that’s faster to deploy, easier to handle, and safer to use on-site. With no joints or welding required, setup and retrieval times reduce downtime and manual labour.
- Waterlord: Designed for high-volume water transfer and mine dewatering (up to 2,500 kPa).
- Waterlord HP: Handles higher pressures (up to 5,000 kPa) for longer or steeper transfer lines.
- Waterlord Extra: Features a double-skin construction for superior abrasion resistance in rough terrain.
- Waterlord Extra HP: Combines maximum pressure (up to 5,000 kPa) and double-skin durability, ideal for extreme pit wall or mining conditions.
Yes. Waterlord hoses are fully reusable across multiple projects, with proper care and storage. Their polyurethane construction resists UV, chemicals, and abrasion, ensuring long-term reliability and minimal maintenance.
Waterlord hoses are used across a wide range of sectors, including mining, agriculture, and emergency response. They are ideal for mine dewatering, high-pressure water transfer, high-pit wall pumping—any application that demands rapid deployment, reliability, and long hose runs in challenging conditions.
